# Linux Server Deployment Deploy MoreLogin on a headless Ubuntu server and automate browser profiles via the Local API — no desktop environment required. ## What You'll Achieve By the end of this guide you will have: 1. A running MoreLogin instance on an Ubuntu 24.04 headless server 2. Network forwarding configured so external machines can connect via CDP (Chrome DevTools Protocol) 3. A working Python automation script that creates, launches, controls, and cleans up browser profiles ## Architecture Overview ``` ┌──────────────────────────────────────────────────────────┐ │ Ubuntu 24.04 Server │ │ │ │ ┌──────────────┐ ┌───────────────────────────────┐ │ │ │ xvfb │───▶│ MoreLogin AppImage │ │ │ │ (virtual │ │ Local API :40000 │ │ │ │ display) │ │ CDP debug : │ │ │ │ │ │ (127.0.0.1, per profile) │ │ │ └──────────────┘ └───────────────────────────────┘ │ │ │ │ │ socat forwarding │ │ │ │ │ 0.0.0.0:40001 → 127.0.0.1:40000 │ │ 0.0.0.0: → 127.0.0.1: │ └──────────────────────────────────────────────────────────┘ │ External machine (Playwright / Puppeteer / Selenium) ``` > [!NOTE] The CDP debug port is **dynamic** — each browser profile gets its own port, returned by the `/api/env/start` endpoint. The diagram above uses `` as a placeholder. ## Prerequisites | Requirement | Details | | --- | --- | | **Operating System** | Ubuntu 24.04 Server (x86_64) | | **Recommended Specs** | 8 vCPU, 8 GB RAM (supports ~5 concurrent profiles) | | **Network** | Outbound internet access; open inbound port `40001` and the forwarded CDP ports you choose, or use SSH tunnels instead | | **Python** (optional) | Python 3.8+ with `pip` for running the example script | ## Step 1 — Install System Dependencies Connect to your server via SSH and install the required packages: ```bash # FUSE support (required for AppImage) sudo apt install -y libfuse2t64 # GTK / accessibility / display libraries sudo apt install -y libatk1.0-0 libatk-bridge2.0-0 libatspi2.0-0 sudo apt install -y libcups2 sudo apt install -y libgtk-3-0 libgdk-pixbuf2.0-0 sudo apt install -y libgbm1 libxkbcommon0 libasound2t64 # Virtual framebuffer (headless display) sudo apt install -y xvfb # TCP forwarder sudo apt install -y socat ``` ### Install Fonts (Optional) If browser pages render without text or show missing characters, install the corresponding font packages: ```bash # CJK (Chinese, Japanese, Korean) sudo apt install -y fonts-noto-cjk fonts-noto-cjk-extra # Arabic sudo apt install -y fonts-noto-color-emoji fonts-noto-extra ``` > For other languages, install the matching [Noto font family](https://fonts.google.com/noto) package. ## Step 2 — Download & Launch MoreLogin ### 2.1 Download the AppImage ```bash wget https://get.morelogin.com/client/prod/linux/x64/2.54.0/MoreLogin_x86_64_2.54.0.AppImage chmod +x MoreLogin_x86_64_2.54.0.AppImage ``` > Replace `2.54.0` with the latest version available from your MoreLogin account or the [download page](https://www.morelogin.com/download/). ### 2.2 Start MoreLogin in the Background Use `xvfb-run` to provide a virtual display, then run the AppImage: ```bash nohup xvfb-run -a ./MoreLogin_x86_64_2.54.0.AppImage --no-sandbox > morelogin.log 2>&1 & ``` Verify it started successfully: ```bash # Check the process is running ps aux | grep MoreLogin ``` > The process may take 5–10 seconds to fully initialize. ## Step 3 — Log In to MoreLogin via API (Required) > [!CAUTION] **You must log in before calling any other Local API endpoint.** On a headless server there is no GUI to log in manually, so you must authenticate via the API. Without this step, all API calls will return: ```json {"status": "error", "code": 401, "message": "Your login status has expired, please log in again"} ``` ### 3.1 Get Your API Credentials Open the MoreLogin desktop client (on any machine where you're logged in) and navigate to **Settings → API & MCP**. Copy the **APP ID** and **API Key** from the **Open API** section: ![MoreLogin API Settings — Copy APP ID and API Key from the Open API section](/assets/image.cfac9a4c31ae47e8434739e42cab4601ee08d737bba4fccba40f2f3bc78e9648.4b463470.png) ### 3.2 Log In via curl Call the login endpoint with your credentials: ```bash curl -X POST http://127.0.0.1:40000/api/user/login \ -H "Content-Type: application/json" \ -d '{ "apiId": "YOUR_APP_ID", "apiKey": "YOUR_API_KEY" }' ``` A successful response looks like: ```json {"code": 0, "msg": null, "data": true} ``` ### 3.3 Verify the Login Confirm the API is ready by listing browser profiles: ```bash curl -s -X POST http://127.0.0.1:40000/api/env/page \ -H "Content-Type: application/json" \ -d '{"pageNo": 1, "pageSize": 1}' ``` > A `{"code":0, ...}` response means you are logged in and the API is ready. > **Checkpoint:** Your MoreLogin server is fully operational. Proceed to [Step 4](#step-4--configure-network-forwarding-socat) for remote access, or jump directly to [Step 5](#step-5--quick-automation-example) if running scripts on the same server. > [!NOTE] The login session persists as long as the MoreLogin process is running. If you restart the AppImage, you will need to log in again. ## Step 4 — Configure Network Forwarding (socat) By default, both the Local API (`:40000`) and CDP debug ports bind to `127.0.0.1`. If you need to access them from an external machine (e.g., your development laptop), use `socat` to forward traffic. > [!WARNING] **Security risk — do not expose these ports to the public internet.** - The Local API has **no built-in authentication** for most endpoints. - A CDP debug port grants **full remote control** of the browser instance (read cookies, inject scripts, capture screenshots). **Recommendations:** - Use an **SSH tunnel** instead of socat for remote access: `ssh -L 40000:127.0.0.1:40000 user@server` - If you must use socat, restrict access with firewall rules to **specific IPs only** - Use a **VPN** or cloud provider security groups to limit inbound traffic - **Never** open ports `40001` / CDP ports to `0.0.0.0` on a public-facing server without IP restrictions ### 4.1 Forward the Local API Port ```bash nohup socat TCP-LISTEN:40001,fork,reuseaddr,bind=0.0.0.0 TCP:127.0.0.1:40000 & ``` > External machines can now reach the API at `http://:40001`. ### 4.2 Forward CDP Debug Ports When you start a browser profile via the API, the response includes a **dynamic** `debugPort` (e.g., `9222`). Each profile may receive a different port. Forward it so external automation tools (Playwright, Puppeteer, Selenium) can connect: ```bash # Example: if debugPort=9222, forward to external port 9223 (debugPort + 1) # Adjust both ports to match the actual debugPort returned by /api/env/start nohup socat TCP-LISTEN:9223,fork,reuseaddr,bind=0.0.0.0 TCP:127.0.0.1:9222 & ``` > [!WARNING] When running multiple profiles concurrently, ensure forwarded ports do not collide with other profiles' debug ports. For example, if profile A gets `debugPort=9222` and you forward to `9223`, but profile B receives `debugPort=9223`, there will be a port conflict. Consider using a larger offset or a dedicated port range. > [!TIP] In production, create socat forwarding **dynamically** after each `/api/env/start` call, using the returned `debugPort`. See the [Python example](#52-create--start--automate--cleanup) for a working implementation. > If running automation scripts **on the same server**, you can skip socat and connect directly to `127.0.0.1`. ### 4.3 Open Firewall Ports If you use socat, restrict access to trusted IPs only: ```bash # Allow only a specific IP (recommended) sudo ufw allow from to any port 40001 proto tcp sudo ufw allow from to any port 9223 proto tcp # Or allow from any IP (NOT recommended for production) # sudo ufw allow 40001/tcp # sudo ufw allow 9223/tcp ``` ### 4.4 Recommended: Use SSH Tunnel Instead For the most secure remote access, use an SSH tunnel — no firewall changes or socat needed. Because the CDP port is **dynamic** (assigned when you start a profile), the workflow is: 1. **Tunnel the API port first:** ```bash # Run this on your local machine ssh -L 40000:127.0.0.1:40000 user@ ``` 2. **Start the profile** via the tunneled API (`http://127.0.0.1:40000/api/env/start`) and read the returned `debugPort`. 3. **Open a second tunnel for the CDP port:** ```bash # Replace with the actual port returned by the API ssh -L :127.0.0.1: user@ ``` 4. **Connect** to `http://127.0.0.1:` from your local Playwright / Puppeteer scripts as if the server were local. > [!TIP] You can combine both tunnels in one command if you know the port range in advance, e.g.: ```bash ssh -L 40000:127.0.0.1:40000 -L 9222:127.0.0.1:9222 -L 9223:127.0.0.1:9223 user@ ``` But in practice it's easier to start the API tunnel first, then add per-profile tunnels as needed. ## Step 5 — Quick Automation Example Below is a minimal Python example showing the full lifecycle of a browser profile. For the complete production-ready script with concurrency and error handling, see the [full example on GitHub](https://github.com/MoreLoginBrowser/MoreLogin-API-Demos/blob/main/MoreLogin-Python/linux_server_test.py). ### 5.1 Install Python Dependencies ```bash pip install requests playwright ``` > Playwright is used here only for its CDP client (`connect_over_cdp`). You do **not** need to run `playwright install` — MoreLogin provides its own browser. ### 5.2 Create → Start → Automate → Cleanup This example assumes the script runs **on the same server** as MoreLogin. For remote scenarios, see the notes after the code. ```python import requests from playwright.sync_api import sync_playwright # ── Configuration ────────────────────────────────────────── # Local: script runs on the SAME server as MoreLogin # Remote: script runs on a DIFFERENT machine — see notes below API_BASE = "http://127.0.0.1:40000" # ① Create a browser profile resp = requests.post(f"{API_BASE}/api/env/create/quick", json={ "browserTypeId": 1, "operatorSystemId": 1, "quantity": 1 }) resp_data = resp.json() assert resp_data["code"] == 0, f"Create failed: {resp_data}" env_id = resp_data["data"]["envIds"][0] print(f"✅ Created profile: {env_id}") # ② Start the profile (headless) resp = requests.post(f"{API_BASE}/api/env/start", json={ "envId": env_id }) resp_data = resp.json() assert resp_data["code"] == 0, f"Start failed: {resp_data}" debug_port = resp_data["data"]["debugPort"] # Dynamic — different for each profile print(f"✅ Started — debug port: {debug_port}") # ③ Build the CDP URL cdp_url = f"http://127.0.0.1:{debug_port}" # ④ Connect via CDP and automate with sync_playwright() as p: browser = p.chromium.connect_over_cdp(cdp_url) page = browser.contexts[0].pages[0] page.goto("https://www.google.com") page.screenshot(path=f"screenshot_{env_id}.png") print(f"✅ Screenshot saved") # Use disconnect() — not close() — to detach without killing the browser. # The profile will be stopped cleanly via the API in step ⑤. browser.disconnect() # ⑤ Stop the profile requests.post(f"{API_BASE}/api/env/close", json={"envId": env_id}) print(f"✅ Profile stopped") # ⑥ Delete the profile requests.post(f"{API_BASE}/api/env/remove", json={"envIds": [env_id]}) print(f"✅ Profile deleted") ``` > [!NOTE] **Running from a remote machine?** Two approaches: **Option A — SSH tunnel (recommended):** Set up SSH tunnels from your local machine to the server (see [§ 4.4](#44-recommended-use-ssh-tunnel-instead)), then keep `API_BASE = "http://127.0.0.1:40000"` and `cdp_url = f"http://127.0.0.1:{debug_port}"` — SSH makes the remote ports appear local. **Option B — socat on the server:** On the **server**, start socat forwarding for the API port and for each CDP port: ```bash # Run these on the SERVER, not on your local machine socat TCP-LISTEN:40001,fork,reuseaddr,bind=0.0.0.0 TCP:127.0.0.1:40000 & socat TCP-LISTEN:$((debug_port+1)),fork,reuseaddr,bind=0.0.0.0 TCP:127.0.0.1:$debug_port & ``` Then in your script, set `API_BASE = "http://:40001"` and `cdp_url = f"http://:{debug_port + 1}"`. ⚠️ Restrict access with firewall rules — see [§ 4.3](#43-open-firewall-ports). > [!IMPORTANT] The `resp.json()["data"]["envIds"]` structure matches the current `/api/env/create/quick` response format. If you encounter a different shape (e.g., `data: ["id1", ...]`), check the [API Reference](/api-reference/browser) for your version — response formats may vary across releases. ## Performance Benchmark The following results were obtained on an Ubuntu 24.04 Server VM (8 vCPU, 8 GB RAM) using the [full stress test script](https://github.com/MoreLoginBrowser/MoreLogin-API-Demos/blob/main/MoreLogin-Python/linux_server_test.py): | Metric | Value | | --- | --- | | **Total runs** | 100 | | **Concurrency** | 4 (simultaneous) | | **Success rate** | 100.0% | | **Total time** | 604.06 s | | **Avg time per task** | 6.04 s | | **Throughput** | 0.17 tasks/s | > These numbers serve as a baseline. Actual performance depends on server specs, network conditions, and page complexity. ## Production Deployment (systemd) For production servers, run MoreLogin as a **systemd service** to get automatic startup on boot, restart on crash, and centralized logging. ### Create the Service File ```bash sudo tee /etc/systemd/system/morelogin.service > /dev/null <<'EOF' [Unit] Description=MoreLogin Browser (headless) After=network-online.target Wants=network-online.target [Service] Type=simple User=root WorkingDirectory=/opt/morelogin ExecStart=/usr/bin/xvfb-run -a /opt/morelogin/MoreLogin_x86_64_2.54.0.AppImage --no-sandbox Restart=on-failure RestartSec=10 StandardOutput=journal StandardError=journal [Install] WantedBy=multi-user.target EOF ``` > Adjust `WorkingDirectory` and `ExecStart` paths to match where you placed the AppImage. > [!TIP] For production, consider creating a dedicated user (e.g., `morelogin`) instead of running as `root`, and adjust file ownership and permissions accordingly. If the AppImage currently requires root privileges, you may keep `User=root`, but isolating the process under a non-root account is a best practice. ### Enable and Start ```bash sudo systemctl daemon-reload sudo systemctl enable morelogin # Auto-start on boot sudo systemctl start morelogin # Start now ``` ### Manage the Service ```bash sudo systemctl status morelogin # Check status sudo journalctl -u morelogin -f # Stream logs sudo systemctl restart morelogin # Restart sudo systemctl stop morelogin # Stop ``` > [!NOTE] After a restart, you must call the [login endpoint](#32-log-in-via-curl) again — the API session does not survive process restarts. For automated recovery, consider adding an `ExecStartPost` script or a health-check cron job that calls the login endpoint after the service starts. ## Troubleshooting ### MoreLogin fails to start ``` AppImages require FUSE to run. ``` **Fix:** Install FUSE support: ```bash sudo apt install -y libfuse2t64 ``` ### Browser pages show blank text / missing characters **Fix:** Install the font package for the target language (see [Step 1 — Install Fonts](#install-fonts-optional)). ### CDP connection refused from external machine **Cause:** CDP debug ports bind to `127.0.0.1` by default. **Fix:** Set up socat forwarding (see [Step 4](#step-4--configure-network-forwarding-socat)) and ensure firewall rules allow the forwarded port. ### `curl` to Local API returns "Connection refused" **Cause:** MoreLogin hasn't finished starting yet, or the process crashed. **Fix:** 1. Wait 5–10 seconds after startup 2. Check `morelogin.log` for errors 3. Verify the process is running: `ps aux | grep MoreLogin` ### API returns 401 "login status has expired" ```json {"status": "error", "code": 401, "message": "Your login status has expired, please log in again"} ``` **Cause:** You haven't logged in via the API, or the MoreLogin process was restarted. **Fix:** Call the login endpoint before any other API call (see [Step 3](#step-3--log-in-to-morelogin-via-api-required)). ## Next Steps | Goal | Link | | --- | --- | | Full Browser API reference | [Browser API](/api-reference/browser) | | Authentication setup | [Authentication Guide](/api-reference/getting-started/authentication) | | Playwright / Selenium / Puppeteer examples | [Automation Examples](/api-reference/examples) | | Complete Linux stress test script | [GitHub — linux_server_test.py](https://github.com/MoreLoginBrowser/MoreLogin-API-Demos/blob/main/MoreLogin-Python/linux_server_test.py) | | CLI quick start | [CLI Guide](/cli/quick-start) |
